Our industrial Forged Flanges are engineered to provide exceptional structural support and leak-proof sealing in high-pressure pipelines, ensuring easy access for cleaning, inspection, and modification.
We supply a massive inventory of flanges across all configurations, including Weld Neck (WNRF) for high-stress applications, Slip-On (SORF) for easy alignment, and Blind Flanges for isolation. Our material expertise spans from Forged Statinless Steel (A105) and Low Temp Steel (LF2) to Austenitic Stainless Steel (304L/316L). For offshore and subsea environments, we offer high-strength Duplex 2205, Super Duplex 2507 (F53/F55), and the hyper-corrosion resistant SMO 254 super austenitic flanges.
All flanges are strictly manufactured in accordance with ASME B16.5, B16.47 Series A & B, and DIN/EN standards. We provide multiple facing options such as Raised Face (RF), Ring Type Joint (RTJ), and Flat Face (FF). Every flange undergoes rigorous ultrasonic testing and dimensional inspection to ensure it withstands extreme thermal expansion and mechanical loads in oil, gas, and power generation sectors.
| Specification | Technical Details |
|---|---|
| Material Grades |
Stainless Steel: F304/L, F316/L, F317L, F321, F310, F347, F904L (ASTM
A182) Duplex & Super Duplex: F51, F53, F55, F60 (ASTM A182 / S31803 / S32750 / S32760) Super Alloys: SMO 254 (F44), Monel 400, Inconel 600/625, Hastelloy C276, Alloy 20 Carbon & Alloy Steel: ASTM A105, A350 LF2, A694 F42 to F70, F11, F22, F91 |
| Flange Types | Weld Neck (WNRF), Slip-On (SORF), Blind (BLRF), Socket Weld (SWRF), Lap Joint (LJFF), Threaded (TRF), Spectacle Blind, Ring Type Joint (RTJ), Long Weld Neck |
| Size Range |
ASME B16.5: 1/2" (15 NB) to 24" (600 NB) ASME B16.47: 26" (650 NB) to 60" (1500 NB) (Series A & B) |
| Pressure Rating / Class | Class 150, 300, 400, 600, 900, 1500, 2500 LBS | PN6, PN10, PN16, PN25, PN40, PN64 |
| Flange Face Types | Raised Face (RF), Flat Face (FF), Ring Type Joint (RTJ), Tongue & Groove (T&G), Male & Female |
| Manufacturing Standards | ASME B16.5, B16.47 Series A & B, MSS-SP-44, API 6A, DIN 2527/2573/2633, EN 1092-1 |
| Manufacturing Process | Forged, Rolled Forged, Machined from Plate (for specific low-pressure use), Heat Treated |
| Testing & Inspection | Ultrasonic Test (UT), Magnetic Particle Inspection (MPI), Positive Material Identification (PMI), Hardness Test, Impact Test (for LF2), Dimensional Verification |
| Value Added Services | CNC Machining, Custom Drillings, Galvanizing, Epoxy Coating, Sand Blasting, Protective Oil Coating, Third Party Inspection |
| Material Category | Standard / Specification | Available Material Grades |
|---|---|---|
| Stainless Steel Flanges | ASTM A182 / ASME SA182 | F304, F304L, F304H, F316, F316L, F316Ti, F317L, F321, F310, F347, F904L |
| Duplex & Super Duplex | ASTM A182 / F51-F60 | F51 (S31803), F60 (S32205), F53 (S32750), F55 (S32760) |
| Super Alloys / 6-Moly | ASTM A182 / B564 | F44 (SMO 254), Monel 400 (N04400), Inconel 625 (N06625) |
| ASTM B462 / B564 | Hastelloy C276, Hastelloy C22, Alloy 20 (N08020), Incoloy 825 | |
| Statinless Steel Flanges | ASTM A105 / A350 | A105 (Standard), LF2 Class 1 & 2 (Low Temp), LF3 |
| ASTM A694 (High Yield) | F42, F46, F52, F56, F60, F65, F70 | |
| Alloy Steel Flanges | ASTM A182 / ASME SA182 | F1, F5, F9, F11 Class 1/2, F12, F22 Class 1/3, F91 |
| Dimensional Standards | ASME / API / DIN / EN | ASME B16.5, B16.47 (Ser. A & B), API 6A, MSS-SP-44, EN 1092-1, DIN 2527-2638 |
